Universal natural resin – hydro-repellent panel for roofs and walls

Applications:
-water-resistant panel threaded on all four sides substituting the wood floor and the the sheath under the roof tiles. The natual resin makes it water-resistant and therefore usable also for plugging external holes for wooden walls.
– in accordance with DIN V 4108-10

Technical data:
thermal conductibility: λ=0,049 W/mK
density: 270 kg/m³
factor of resistance to the diffusion of water vapour: μ=5

Prerogatives:
– high resistance to compression, can be tread on even if placed resting on the rafters
– great thermal resistance (against summer heat)
– good thermal insulation
– elimination of thermal bridges
– particularly breathable, allows for the elimination of the roof ventilation
– hermetic threading with perfect performance in the rain at an angle of ≥ 20°
– can remain as a temporary cover for 4 weeks
– efficace efficient protection from wind, dust humidity an noise
– regulator of atmospheric humidity
– significant contribution to maintaining the ideal home “climate”
– ecological and can be disposed of anywhere
– recyclable
– sanctioned by the Deutsches Institut für Bautechnik (German institute for building technology)

Packaging:



thickness
[mm]

Size [mm]

Surface [mm]

weight[kg/m²]

pieces/pallet

m²/pallet

weight/pallet[kg]

22

2500 x 580

2520 x 600

5,7

100

145

ca. 826

35

2500 x 580

2520 x 600

9,1

62

89,9

ca. 818

52

2500 x 580

2525 x 605

13,5

42

60,9

ca. 822

60

2500 x 580

2525 x 605

15,6

36

52,2

ca. 814

80

1750 x 580

1775 x 605

20,8

26

26,4

ca. 549

100

1750 x 580

1775 x 605

26

22

22,3

ca. 580
